CONT 18A AC3 1NO-1NC 120VAC

CONT 18A AC3 1NO-1NC 120VAC

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Part Number MC2D1811G7
Weight 0.3700
Type Reversing
Poles 3 Pole
Coil 120VAC 50/60Hz
AUX 1NO / 1NC
IND Amps 18A
RES Amps 32A
HP@ 208V, 3ph 5
HP@ 240V, 3ph 5
HP@ 480V, 3ph 10
HP@ 600V, 3ph 15
Approvals UL, CSA, CE
